Name: BIOSTAR Z590MHP 11th/10th Gen Micro ATX Motherboard
Brand: Biostar
SKU: Z590MHP
Price: 9000.00 BDT
Availability: InStock

BIOSTAR Z590MHP 11th/10th Gen Micro ATX Motherboard

BIOSTAR Z590MHP 11th/10th Gen Micro ATX Motherboard

Based on 0 reviews. - Write a review

9,000৳

Ex Tax: 9,000৳

Stock: In Stock
Brand: Biostar
Model: Z590MHP
SKU: Z590MHP

1411 views

Qty

Add to Cart

Buy Now Buy Now

Add to Wish List Compare this Product

It is requested to know about the stock and delivery of the product before ordering

View more info

Brand & Model
Brand	Biostar
Model	Z590MHP
Details
Chipset	Intel Z590
CPU SUPPORT	Socket 1200 for 10th / 11th Gen Intel Core™, Pentium and Celeron processors<br /> * Please refer to www.biostar.com.tw for CPU support list.
MEMORY	Supports Dual Channel DDR4 – 4000(OC)/ 3866(OC)/<br /> 3800(OC)/ 3733(OC)/ 3600(OC)/ 3200/ 2933/ 2800/ 2666/ 2400/ 2133<br /> 2 x DDR4 DIMM Memory Slot, Max. Supports up to 64 GB Memory<br /> Each DIMM supports non-ECC 4/8/16/32 GB DDR4 module<br /> * Please refer to www.biostar.com.tw for Memory support list.
INTEGRATED VIDEO	By CPU model<br /> Supports DX12<br /> Supports HDCP
STORAGE	4 x SATA III Connector (6Gb/s)<br /> Supports AHCI, RAID 0, 1, 5, 10 & Intel Rapid Storage Technology<br /> 1 x M.2 (M Key) Socket:<br /> Supports M.2 Type 2242/ 2260/ 2280 SSD module.<br /> Supports PCIe 3.0 x4 (32Gb/s) & SATA III (6Gb/s) SSD<br /> * When using SATA SSD module on PCIE-M2_1 slot, the SATA_1 connector will be disabled.
LAN	Intel I219V<br /> 10/ 100/ 1000 Mb/s auto negotiation, Half / Full duplex capability
Audio	Realtek ALC897<br /> 7.1 Channels, High Definition Audio
USB	4 x USB 3.2 (Gen1) ports<br /> (2 on rear I/Os and 2 via internal headers)<br /> 6 x USB 2.0 ports<br /> (4 on rear I/Os and 2 via internal headers)
EXPANSION SLOT	2 x PCIe 3.0 x1 Slot<br /> 1 x PCle 3.0/ 4.0 x16 Slot (x16 mode)<br /> *The PCle 4.0 only depends on Rocket Lake CPUs.
REAR I/O	1 x PS/2 Keyboard<br /> 1 x PS/2 Mouse<br /> 1 x HDMI Port (HDMI1.4)<br /> 1 x VGA Port<br /> 2 x USB 3.2 (Gen1) Ports<br /> 4 x USB 2.0 Ports<br /> 1 x LAN port<br /> 3 x Audio Jack
INTERNAL I/O	4 x SATA III Connector (6Gb/s)<br /> 1 x USB 3.2 (Gen1) Header<br /> (each header supports 2 USB 3.2 (Gen1) ports)<br /> 1 x USB 2.0 Header<br /> (each header supports 2 USB 2.0 ports)<br /> 1 x 8-Pin Power Connector<br /> 1 x 24-Pin Power Connector<br /> 1 x CPU Fan Connector<br /> 1 x System Fan Connector<br /> 1 x Front Panel Header<br /> 1 x Front Audio Header<br /> 1 x Clear CMOS Header<br /> 1 x COM Port Header
Networking	CPU / System Temperature Monitoring<br /> CPU / System Fan Monitoring<br /> Smart / Manual CPU Fan Control<br /> CPU/DDR Voltage Monitoring
DIMENSION	Micro ATX Form Factor Dimension: 18.5cm x 22.6cm ( W x L )
OS SUPPORT	Supports Windows 10 (64bit) / 11(64bit)<br /> ※Biostar reserves the right to add or remove support for any OS with or without notice.
ACCESSORIES	2 x SATA Cable<br /> 1 x I/O Shield<br /> 1 x DVD Driver<br /> 1 x Quick Guide
Warranty & Others
Bundled Software	BullGuard
Caution	The specification and pictures are subject to change without notice!

The Biostar Z590MHP is a Micro ATX motherboard designed for Intel's 10th and 11th generation Core, Pentium, and Celeron processors, featuring the LGA 1200 socket and the Intel Z590 chipset. It supports dual-channel DDR4 memory with speeds up to 4000(OC) MHz, accommodating up to 64GB across two DIMM slots. The motherboard includes one PCIe 4.0 x16 slot (operating at PCIe 3.0 speeds unless paired with a Rocket Lake CPU), two PCIe 3.0 x1 slots, and one M.2 socket (M Key) supporting both PCIe 3.0 x4 and SATA III SSDs. Storage options are further expanded with four SATA III (6Gb/s) connectors, supporting AHCI, RAID 0, 1, 5, 10, and Intel Rapid Storage Technology. Connectivity features comprise one HDMI port, one VGA port, four USB 3.2 Gen1 ports, and six USB 2.0 ports. Networking is handled by the Intel I219V Gigabit Ethernet controller, and audio is provided by the Realtek ALC897 codec, delivering 7.1-channel high-definition audio. The motherboard also supports CPU/System temperature monitoring, fan control, and voltage monitoring. Its compact Micro ATX form factor (18.5cm x 22.6cm) makes it suitable for space-constrained builds. The Biostar Z590MHP is compatible with Windows 10 and 11 (64-bit) operating systems.

What is the BIOSTAR Z590MHP 11th/10th Gen Micro ATX Motherboard price in bd 2026?

The latest price of BIOSTAR Z590MHP 11th/10th Gen Micro ATX Motherboard in Bangladesh is 9,000৳. You can buy the BIOSTAR Z590MHP 11th/10th Gen Micro ATX Motherboard at best price from our website or visit any of our showrooms.
